Text to Audio
TOX name base_txt_to_audio
Summary
A TouchDesigner component for generating synthetic audio with the Google Gemini API.
Controls
Refer to the Common Controls for a list of all available parameters.
| Parameter Name | Parameter | Type | Description |
|---|---|---|---|
| Input Resolution | Inputresolution | menu | Downscale options for reducing the image resolution - reducing your input resolution by a half or quarter will help maintain high performance |
| Include Image | Includeimage | toggle | Specifies if an input image will be used when submitting the prompt to the Gemini API |
| Export Audio File | Exportaudiofile | pulse | Allows for exporting audio from component - using this parameter will open a dialog asking you where to save the file |
| File | File | file | (Read Only) Path of source. |
| Reload | Reloadpulse | pulse | Instantly reload the file from disk. |
| Play | Play | toggle | Audio will playback when this is set to 1 and stop when set to 0. |
| Speed | Speed | float | This is a speed multiplier which only works when Play Mode is Sequential. A value of 1 is the default playback speed. A value of 2 is double speed, 0.5 is half speed and so on. This node can not play audio backwards so negative values will not work well. |
| Cue | Cue | toggle | Jumps to Cue Point when set to 1. Only available when Play Mode is Sequential. |
| Pulse Cue | Cuepulse | pulse | Instantly jumps to the Cue Point. |
| Repeat | Repeat | menu | Repeats the audio stream when the end is reached. |
| Volume | Volume | float | Set the level the file is read in at. A setting of 1 is full signal while 0 is muted. |
| Fade In/Out | Fade | toggle | about |
Outputs
| Output Index | Name | Type | Description |
|---|---|---|---|
| 0 | out_response | TOP | The video output from the Google Gemini API |
| 1 | out_response_audio | CHOP | The video audio output from the Google Gemini API |
